EmStat4WE

With this polypotentiostat one electrochemical cell can be equipped with 1, 2, 3 or 4 working electrodes and all of these will be measured parallel. The EmStat3 4WE consists of a standard EmStat3 potentiostat and additionally three polypotentiostat (bipotentiostat-like) modules.
All techniques supported by EmStat3 are available for the EmStat3 4WE.

Opis

EmStat3 4WE Main potentiostat Polypotentiostat modules
dc-potential range ± 3.000 V ± 3.000 V
compliance voltage ± 5 V ± 5 V
dc-potential resolution 0.1 mV 0.1 mV
max. dc-offset error 2 mV 3 mV
potential accuracy 0.2 % 0.2 %
current ranges 1 nA to 10 mA (8 ranges) 1 nA to 10 mA (8 ranges)
maximum current ± 20 mA typical and ± 15 mA minimum for the sum of WE1, W2, W3 and W4
current resolution 0.1% of current range, 1 pA at lowest current range
electrometer amplifier input  > 100 GOhm // 4 pF > 100 GOhm // 4 pF
rise time    approx. 100 μs approx. 100 μs



Housing:
dimensions 12 cm x 8.5 cm x 3,5 cm
weight  250 g
power     5 V external power supply (included)
interfacing    USB
PC recommendations Windows Vista,  7, 8 or 10 (32 and 64 bit) Dual core processor with 2 GB RAM

The current is measured using a zero resistance ammeter (ZRA).

MultiTrace is our standard software for multichannel instruments. It is based on PSTrace  and comes standard on a CD as well as download. The channels can be controlled all at once or get individual commands. Also the scripting feature can be used individually or for all channels.
