EmStat Blue is a small and low cost potentiostat with research grade capabilities. It has eight current ranges from 1 nA to 100 mA (EmStat3+ Blue) full scale, with a minimum resolution of 1 pA. It provides the most relevant electroanalytical measurement techniques and is used with the PSTrace software or with PStouch for Android.
|EmStat Blue version:||3||3+|
|dc-potential range||± 3.000 V||± 4.000 V|
|compliance voltage||± 5 V||± 8 V|
|dc-potential resolution||0.1 mV||0.125 mV|
|dc-potential accuracy||0.2 %||0.3 %|
|current ranges||1 nA to 10 mA (8 ranges)||1 nA to 100 mA (9 ranges)|
|maximum current||± 20 mA typical
and ± 15 mA minimum
|± 100 mA typical|
The current is measured using a zero resistance ammeter (ZRA).
|current resolution||0.1% of current range, 1 pA at lowest current range|
|current accuracy (deviation)||≤ 1 %of current range at 1 nA
≤ 0.5 % at 10 nA
≤ 0.2 % at 100 nA to 100 uA
≤ 0.5 % at 1 mA, 10 mA and 100 mA
all with max. 0.2 % offset error
|electrometer amplifier input||> 100 Gohm // 4 pF|
|rise time||approx. 100 μs|
|sensor connection||shielded cable with circular connector for
WE, RE, CE and Sense (EmStat3+ only)
|housing||anodized aluminium: 10 x 6.0 x 2.8 cm|
5 V, min. 130 mA (ES3) or 500 mA (ES3+)
|battery time||> 8 hours with cell off
> 6 hours with continuous cell on 1 uA current
full charge takes approx. 3 hours
|communication||mini USB or Bluetooth|
|auxiliary port present||yes|
|external I/O options||analog: 1 input 1 output channel
(both 0 V – 4.096 V)
digital: 1 input, 4 output lines
(maximum rating: -0.3 V to 5.3 V)
EmStat Standard vs EmStat Blue
|size||6.7 x 5.0 x 2.8 cm||10.0 x 6.0 x 3.4 cm|
|weight||85 g||250 g|
|communication||USB||USB + Bluetooth|
|sensor connector||LEMO||LEMO + SPE|
Main extensions for EmStat Blue:
- Multiplexer for using up to 8 or 16 cells with one potentiostat
- Pt1000 temperature sensor.
- Magnetic stirrer for stripping analysis applications.
- USB galvanic isolator for floating measurements.
- Differential Electrometer Amplifier (DEA) for use as floating voltage amplifier with differential input and single output for measuring an auxiliary signal between -5 to +5 V or -10 to +10 V.
Click here to see all EmStat Blue compatible extensions and accessories.
